LightSPEED Aviation Headsets

MODEL Thirty 3G Twenty 3G 20XLc 15XLc QFRXCc QFRSoloSSc QFRSolo/c Active 28-30dB 22-24dB 22-24dB 16-18dB 10-12dB Passive Only Passive Only Passive 12-22dB 12-22dB 12-22dB 12-20dB 24-26dB 26dB 28.7dB NRR Battery Hours 2 AA/ 30 hrs 2 AA/ 40 hrs 2 AA/ 50 hrs 2 AA/ 50 hrs 2 AA/ 25 hrs N/A N/A Auto Shut-Off Yes Yes Yes Yes Yes N/A N/A PST EQ Yes Yes No No No N/A N/A Weight 16 oz 16 oz 15 oz 15 oz 14 oz 13 oz 11 oz Cell Phone Interface Yes Yes Yes Yes Yes Yes Yes Music Interface Yes Yes Yes Yes Yes No No Mono/Stereo Yes Yes Yes Yes Yes Yes Yes Warranty 5 years 5 years 3 years 3 years 3 years 3 years 3 years Heli with Coil Cord & Plug Yes Yes Yes Yes Yes Yes Yes List Price* $599 $479 $439 $379 $379 $219 $159

* SportFlyingShop.com prices below

ANR HEADSETS 3G Series Thirty 3G Headset Twenty 3G Headset XL Series 20XLc Headset 15XLc Headset QFR Series QFRXCc Headset PASSIVE HEADSETS QFR Series QFRSoloSSc Headset QFRSolo/c Headset SportFlyingShop.com recommends the QFRXCc headset for operation in noisy aircraft powered by higher-revving engines such as Rotax, Hirth, etc.

 Thirty 3G Headset 28-30dB of Active Cancellation
12-22dB of Passive Attenuation

•	Cell/Satellite Phone Interface
•	Patented AES™ "Auto Shut-Off" Powers Down the Active Electronics if System is Left Unattended
•	Battery Status Indicator
•	ANR Power for up to 30 Hours on just Two AA Batteries
•	Auxiliary Audio Interface for Music or Audible Checklist/Warnings
•	Personal Side-Tone EQ with Bass and/or Treble Boosting
•	Dual Volume Controls, Stereo or Mono switchable
•	Adjustable Gain Pre-amp Allowing for Field 'Balancing' of Mic Sensitivities
•	Temperature Sensitive Confor-Foam™ Ear Seals
•	Weighs Under 16 Ounces
•	Panel Power Option Available
•	Helicopter Version Available
•	5-Year Warranty
•	Padded Headset Bag, Mic Wind Screen, and Batteries Included

General Data
Connectors: .250" Stereo Headphone Plug .206" Stereo Microphone Plug
Power Supply: Small In-Line with Left and Right Ear Level Control, Stereo/Mono Switch, Powered by Two AA Batteries
Battery Status Indicator: Red LED Low Battery Indicator
Operating Time: 25-30 hours
Weight: 15.8 oz

Headphone Data
Transducer: Dynamic, Selective Frequency Amplified for Enhanced Speech Intelligibility
Frequency Response: 20-30,000 Hz
Nominal Impedance: 120 ohms Stereo 60 ohms Mono

Microphone Data
Transducer Principle: Noise Cancelling Electret
Frequency Response: 200-5000 Hz
Maximum SPL: 114 dB
Terminating Impedance: 470 ohms
Operating Voltage: 8-16 V DC Appx 5-12mA

Qty: LightSPEED Thirty 3G Headsets, $595

 Twenty 3G Headset

Connectors: .250" Stereo Headphone Plug .206" Stereo Microphone Plug
Power Supply: Small In-Line with Left and Right Ear Level Control, Stereo/Mono Switch, Powered by Two AA Batteries
Battery Status Indicator: Red LED Low Battery Indicator
Operating Time: 35-40 hours
Weight: 15.8 oz

 20XLc Headsets 22-24dB of Active Cancellation
12-22dB of Passive Attenuation

•	Cell/Satellite Phone Interface
•	Patented AES? "Auto Shut-Off" Powers Down the Active Electronics if System is Left Unattended
•	Small In-Line Battery Control Box
•	Battery Status Indicator
•	ANR Power for more than 50 Hours on just Two AA Batteries
•	Auxiliary Audio Interface for Music or Audible Checklist/Warnings
•	Dual Volume Controls, Stereo or Mono switchable
•	Adjustable Gain Pre-amp Allowing for Field 'Balancing' of Mic Sensitivities
•	Soft 1-1/2" Thick Temperature Sensitive Confor-Foam? Ear Seals
•	Weighs Just 15 Ounces
•
